Rolling Drum Type Sand Blaster is a newly upgraded product manufactured using advanced Japanese technology. It employs a roller oscillation mechanism, where the roller not only rotates continuously but also oscillates up and down during shot blasting, ensuring complete tumbling and mixing of the workpiece inside for a uniform and thorough cleaning effect. The shot blasting roller features a unique construction that can clean general castings, forgings, and cast steel parts, even thin and small special parts without damage. The loading and unloading mechanism operates smoothly, preventing workpiece collisions and allowing for gentle and complete loading and dust removal, facilitating operation. Its simple structure and few vulnerable parts reduce maintenance costs.
Rotary Barrel Shot Blasting Machine, Rolling Drum Type Sand BlasterRotary barrel shot blasting machine is suitable to blast work-pieces in batch, the work-piece keep mixing and tumbling under abrasive stream while the barrel or drum keeps rotating and tilting. With the advantages of high efficiency, fine blasting coverage and thermal resistance, rotating drum shot blasting machine is welcomed by customers having high production output. Automatic load tipper and unload are available for higher producing speed and lower labor cost, the ripping angle and tipping speed are according to sensitivity of work-pieces.
Model | QGT10 | QGT15 |
Rolling diameter * length(mm) | φ1000x1300L | φ1500x1600L |
Maximum external dimensions length(mm) | 450 | 600 |
Maximum mass of a single room(kg) | 30 | 40 |
Maximum slewing diameter(mm) | 300 | 350 |
Shot blasting machine completion rate(kw) | 22 | 30 |
Processing capacity(m³) | 0.5m³ | 0.6m³ |
Maximum load capacity(kg) | 800 | 1500 |
Total power(kw) | 48kw | 57kw |
Rotating barrel System
The drum is manufactured in anti-wear steel with no joints. There are holes in the bottom of the drum, the size of the holes depends on the dimensions of the work pieces as well as on the graining and the quantity of the effluent abrasives.
The smooth, constant rotation of the drum makes the cleaning of the parts uniform.
The drum can not only rotate ,but also up and down shake.
he machine with loading and unloading system. After the blasting process the drum swings into the unloading position. The treated work pieces arrive on a screen conveying trough which separates the residual abrasive and transports the pieces to forthcoming boxes.
Applications
Automative
Iron, steel and metal foundries
Heat treat operations
Small stamping parts manufacturers
Features
Efficient and uniform blast cleaning effect
Thin and small special parts can also be processed
Simple and accurate input and discharge
Simple maintenance
FAQ:
1.Do you sell steel shot or steel grit which can be uses in shot blasting machine?
We can provide products such as steel shot, steel sand, steel wire cutting shot, stainless steel shot, and other metal abrasives related to surface cleaning and anti corrosion.
2.How long is your delivery time?
Generally Standard shot blasting machine 7-20 workdays. Non Standard Shot blasting machine is 20-60 workdays. Shot peening machine is 30-60 workdays. It is according to quantity and machine model.
3.What is the shot blasting machine?
Shot blasting is a method used to clean, strengthen (peen) or polish metal. Shot blasting is used in almost every industry that uses metal, including aerospace, automotive, construction, foundry, ship building rail, and many others.
4.What are your pre-sales and after sales services?
Pre-sales services include: consulting products, samples, technical solutions and quotations; After sales service includes: 24-hour response, engineers' online guidance, engineers' installation in the customer's factory, and training on how to install and use the product.
