Compact design, simple operation principle, can be used in single machine and specially suitable for automatic production line. Steel or rubber tumble belt configuration.
Simple Description
PRODUCT FEATURE 1.Compact design, simple operation principle, can be used in single machine and specially suitable for automatic production line. 2.Automatic loading and unloading configuration 3.Steel or rubber tumble belt configuration. Wearing rubber belt: reduce collision and damage of work pieces, lower noise of machines. Steel rubber belt: large loading capacity and long service life. 4.Running of tumble belt makes work pieces gently and continuously overturn for all-round blasting. The tumble belt can realize positive and negative motion, work pieces cleaning in positive motion, automatic unloading in negative motion 5.Equipped with belt conveyor or vibrating conveyor, work pieces conveying system after unloading to improve automation, combine finished work pieces in automatic production line together. 6.Wear resistant protective plates within blasting chamber, pressed tightly by nuts, easy to change. PRODUCT APPLICATION: 1.Mainly suitable for blasting, rust removal, oxide skin removal and surface strengthening of many varieties, large and medium-sized batch production of medium and small-sized castings, forgings, stamping parts and heat-treated pieces, specially for surface cleaning and strengthening of parts no collisions.
| Product Parameter | |||||||
|---|---|---|---|---|---|---|---|
| Product Name | Roller Conveyor Shot Blasting Machine | ||||||
| Use | Deflashing, Descaling / Stripping, Burnishing, Container / Bottle Cleaning | ||||||
| Cleaning Process | steel shot cleaning | ||||||
| core components | PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump | ||||||
| cleaning type | Roller Conveyor Shot Blasting | ||||||
| power(w) | Customized | ||||||
| After-sales Service Provided | Field installation, commissioning and training | ||||||
| Machine type | Automatic | ||||||
| Function | Clean Structural Steel | ||||||
| Marketing Type | Ordinary Product | ||||||
| Fuel | Q6910 | Q6912 | Q6915 | Q6920 | Q6925 | Q6930 | Q6940 |
| Effective Cleaning Width(mm) | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
| Inlet Size(mm) | 1000*260 | 1200*400 | 1500*400 | 2000*400 | 2500*800 | 3000*800 | 4000*400 |
| Length(mm) | 1200- 12000 | 1200- 12000 | 1200- 12000 | 1200- 12000 | 3000- 12000 | 2400- 12000 | 4500- 18000 |
| Roller Conveying Speed(m/min) | 0.5-4 | 0.5-4 | 0.5-5 | 0.5-4 | 0.5-4.5 | 0.5-4 | 2-8 |
| Thickness(mm) | 4-60 | 4-60 | 4-60 | 4-60 | 4-60 | 4-110 | 4.5-100 |
| Blast Capacity(kg/min) | 4*250 | 4*250 | 4*250 | 4*250 | 6*250 | 6*360 | 8*360 |
| Initial Capacity(kg) | 4000 | 4000 | 4000 | 4500 | 4500 | 8000 | 11000 |
| Height of Rolling Brush(mm) | No | 200 | 350 | 450 | 600 | 850 | 900 |
| Ventilation Capacity(m³/h) | 12000 | 17560 | 19000 | 19550 | 27758 | 28050 | 38000 |
| Total Power(kw) | 78 | 78.3 | 113.5 | 156.6 | 224.55 | 204.8 | 293.6 |
QINGDAO XIANGMAO MACHINERY MANUFACTURING CO., LTD
QINGDAO XIANGMAO MACHINERY is a world-known producer of shot blasting machines with knowledge and experience for more than 10 years, we offers a large range of shot blasting equipment. We can offer shot blasting machine which is tailor-made for diverse requests, because we have our own development, engineering, production and after-sales service.
FAQ
1.Q:How to choose the right machine?
A:Show the biggest size,weight,productivity of your wokpiece,will design the best solution for you.
2. Q: What payment term?
A:T/T,L/C, 30% deposit by T/T,balance is before shipment.
3. Q:How to delivery the machine?
A: By 40'HQ container or by Truck.
4.Q:How to Install machine?
A:1-1 install assistance & operation training on site by experienced engineer for big and complicated machine.
Normal machine supply the installation manual,photo and video.
5.Q:After sale service?
A:Full stock for spare parts, regular after sale service and 24/7 hours on line.
6. Q:Why choose us?
A:We focus on surface cleaning over 10 years,supply you one-stop solution with professional design.
