Automatic Iron Mold Coated Resin Sand Casting Line Output Grinding Ball Casting Producing Machine Steel Ball Making Machine for Steel Ball Production

Specification

Iron Mold Sand Covering Cast Grinding Media Balls Production Line

Product Description:

Harnessing hydraulic and pneumatic systems, this case optimizes their combination and adopts an

open, flexible conveyance, multi-level supply drive. It includes a molding line, casting line, and two motorized roller tracks. The molding line features two stepper box feeders, dividing it into three independent

zones: opening, molding, and closing. This line ensures non-interference across six areas with complementary functions. Two motorized tracks manage sand boxes for molding and casting lines, preventing interference and enhancing production efficiency.

Specifications:

The line includes covered sand molding, co-box, casting, sub boxes, metal cooling, coating, etc.

Design basis and main parameters:

1. Production: 5,000 tons/year (based on ball diameter D80 min)

2. Operation: Three shifts (8 hours each)

3. Annual working: 300 days

4. Ball diameter: Dia 60mm - Dia130mm

5. Productivity: 100 models/h

6. Dimensions: Upper/Lower plate 420x420mm

7. Online Mold: Approx. 120 pairs

Analysis of mold action sequence:

mold separation (up/bottom) → scrabble ball → bottom turnover → 4-station clean → inspect → heat mold → 4-station sand injection → inspect → bottom turnover → close mold.

Advantages of Iron mold coated sand casting line:

1. Compact area: 10,000 tons/year line covers ~300 m².

2. Minimal labor: 4 permanent jobs.

3. Low energy: <100kw.

4. Product qualification >98%.

5. Versatile: One line adapts to multiple molds/products, reducing costs.

6. Compatible with various pouring methods for different products.
